Field Report: M4 Dynamic Engine

1. Objective: The “Zero-Downtime” Architecture

• Status: M4.6 STABLE
• Focus: Dynamic Maps & Ring Buffer

M3 proved DPI was possible; M4 makes it operational. We moved from a static C-hardcoded scanner to a Split-Plane Architecture where policy is injected from User Space at runtime.

Key Capabilities:

• Dynamic Policy: Signatures are loaded into BPF_MAP_TYPE_ARRAY.
• High-Speed Telemetry: Replaced slow trace_pipe with BPF_MAP_TYPE_RINGBUF.
• Live Reload: Updates rules via SIGHUP without restarting the firewall.

---

2. The Visual Controller (Go)

We developed a custom User Space Controller (hyperion_ctrl) using the cilium/ebpf library. It manages the lifecycle of the maps and renders a structured, color-coded dashboard.

Figure 1: The Hyperion M4.6 Controller handling a live reload event.

---

3. Technical Implementation

The Kernel Plane (Enforcer)

The XDP program no longer contains strings. It loops through a Map of active policies.

/* M4 Logic: Dynamic Map Lookup */
struct policy_t *pol = bpf_map_lookup_elem(&policy_map, &key);
if (pol && pol->active) {
    // Scan payload against pol->signature...
}

The Control Plane (Manager)

The Go controller handles the “Live Reload” logic using Linux Signals.

/* M4 Logic: Zero-Downtime Update */
sig := <-sigChan
if sig == syscall.SIGHUP {
    fmt.Println("[!] Reloading signatures...")
    reloadMaps() // Updates Kernel Map atomically
}

---

4. Performance & Stability

M4.6 represents the Production Candidate.

1. Safety: Loops are bounded to 32 bytes to guarantee Verifier compliance on Kernel 5.4+.
2. UX: ASCII Art banners and ANSI-colored alerts provide immediate operator feedback.

Next Phase: M5 (Stateful Flow Tracking).
